The 0.8mm Single Slot Side-In Male Connector (2×6P) is a high-density, miniaturized PCB connector designed for electronic systems that require reliable, space-efficient board-to-board connections. With a dual-row 2×6 pin (12-pin) configuration and an ultra-compact 0.8mm pitch, this connector enables stable power and signal transmission in constrAIned layouts such as IoT devices, embedded systems, industrial controls, smart consumer electronics, and medical instruments.
Manufactured using high-performance insulating materials and precision-engineered, gold-plated contacts, it provides:
Excellent electrical conductivity
Strong corrosion resistance
High reliability over hundreds of mating cycles
Stable performance under vibration, temperature changes, and frequent use
The side-in horizontal mating structure reduces the Z-axis height, making it ideal for compact modules where PCB space optimization is critical.
Provides multiple signal and power channels while maintaining a small PCB footprint.
(high-density PCB connector, 12-pin board-to-board connector)
Space-Saving Side-Entry Mating Design
Horizontal insertion reduces vertical height requirements, ideal for slim, portable devices.
Ensures:
High-frequency / high-speed data stability
Long-term corrosion resistance
(gold-plated connector, high-speed signal connector)
Heat-resistant insulating plastic protects against:
Dust
Moisture
Vibration
Thermal cycling
Maintains stable conductivity across hundreds of mating cycles, supporting demanding industrial and consumer applications.
Side-in design supports quick push-in or screw-based assembly, reducing production time and maintenance costs.
The 2×6P 0.8mm side-in male connector is widely used across industries requiring compact, high-reliability PCB interconnections:
Wearable devices
Smart home products
Tablets & portable gadgets
Compact cameras
High-density sensor modules
Wireless communication modules
Edge computing devices
Portable diagnostic tools
Monitoring equipment
Smart medical sensors
Motion control boards
PLC modules
Compact industrial controllers
RF units
Network interface modules
Compact router boards
Fast assembly for high-density PCB evaluation and product development.
(IoT connector, embedded connector, industrial PCB connector, compact side-entry connector)
A: The connector offers 12 pins arranged in a 2×6 dual-row layout with a compact 0.8mm pitch.
A: Yes. The gold-plated contacts minimize signal loss, interference, and noise, making it suitable for high-speed digital lines.
A: It is engineered to support hundreds of mating cycles with stable electrical performance.
A: Yes. It is suitable for power, low-voltage control signals, and high-speed data.
A: No. The side-in design provides quick, tool-free installation. It supports both push-in and screw mounting.
