The SATA 15P SMT Type Male Connector is a compact, low-profile board-level interface designed for reliable power transmission in modern SATA-based systems. With its single-row 15-pin configuration, this SMT connector delivers stable electrical performance while supporting efficient PCB layout, making it ideal for devices requiring high-density and space-saving designs.
Built using high-temperature, insulation-grade plastics and gold-plated contacts, the connector ensures low Contact Resistance, excellent electrical conductivity, and long-term durability—even in demanding industrial or compact electronic environments. The SMT mounting design enables automated pick-and-place assembly, enhancing production efficiency, placement accuracy, and cost control during mass manufacturing.
Ideal for compact devices requiring efficient PCB utilization and High-Density Connector placement.
Supports SMT pick-and-place and reflow soldering, reducing manual labor and improving manufacturing repeatability.
Ensures low resistance, high conductivity, and stable performance under high-speed data or power transmission.
Resists vibration, dust, temperature changes, and frequent mating cycles.
Compatible with various SATA-based electronic systems and embedded designs.
SMT footprint simplifies integration, lowers assembly cost, and enhances mass-production scalability.
The SATA 15P SMT male connector is widely used across industries requiring compact and reliable power interfaces:
Smartphones, tablets, portable media devices, mini PCs, smart home devices.
Routers, access points, modems, network storage equipment (NAS).
PLC controllers, industrial IoT devices, robotics control boards, sensors.
Portable diagnostic devices, monitoring modules, data acquisition units.
HDD/SSD interface boards, compact server boards, micro-computing platforms.
Thanks to its rugged construction, the connector ensures stable operation in vibration-prone, dust-exposed, or thermally demanding environments.
It serves as a compact power interface for PCB designs requiring stable SATA-based electrical connections, including computing, communication, and embedded systems.
Yes. Its gold-plated contacts offer low contact resistance, enabling clean and stable high-frequency performance.
Absolutely. SMT mounting supports automated placement and reflow soldering, improving accuracy and throughput in mass production.
It is primarily used for SATA power delivery, but depending on circuit design, it can support signal transmission as well.
The connector withstands vibration, temperature fluctuations, dust exposure, and frequent mating cycles without performance degradation.
Yes. Custom pin length, plating thickness, packaging, and mechanical design adjustments are avAIlable upon request.
