0.8x5.2 Single Slot Side-In Female Connector 2x7P

Product Introduction

The 0.8×5.2 Single Slot Side-In female connector (2×7P, 14-pin) is a high-density, space-saving board-to-board connector designed specifically for compact electronic devices that require stable and efficient signal transmission. With its side-entry (horizontal) mating structure, the connector reduces vertical PCB height and enables clean, low-profile layouts.

Thanks to its dual-row 2×7 configuration, this side-in female connector provides reliable power and data connections while mAIntaining a compact footprint. The housing is made from high-performance insulating material, and the contacts feature gold-plating for improved conductivity, corrosion resistance, and long-term durability.

Engineers choose this 14-pin side-in connector because it delivers consistent performance, easy installation, and high reliability, even in demanding environments such as robotics, automation, or portable devices.

Product Advantages

Compact 0.8×5.2 Side-In Design

– Ideal for small PCB layouts, handheld devices, IoT modules, and miniaturized electronics.

High-Density 2×7P (14-Pin) Configuration

– Supports multi-signal transmission, power + signal combinations, and high-speed communication.

Gold-Plated Contacts for Better Conductivity

– Low Contact Resistance
– High Signal Integrity
– Strong anti-corrosion performance
– Suitable for high-frequency, high-speed data applications

Durable for Repeated Mating Cycles

– Engineered for hundreds of mating/unmating cycles without degradation.

Stable Mechanical Structure

– Reinforced housing protects against:

Vibration

Dust

Moisture

Thermal fluctuations

Easy Assembly for Fast Production

Side-entry slide-in design reduces installation time, supports manual assembly and automated SMT/AI production

Connector Type: Single Slot Side-In Female Connector

Pin Count: 2×7 (14 pins)

Pitch: 0.8 mm

Mounting Style: Horizontal / Side-In

Application Category:

board-to-board connector

PCB connector

side-entry connector

high-density female connector

These terms help strengthen SEO coverage for global buyers searching by specifications, design structure, or connector type.

Typical Applications

The 2×7P Single Slot Side-In Female Connector is widely used across industries requiring stable, compact, and high-density interconnect solutions, including:

Consumer Electronics

• Wearables

• Smart handheld devices

• Portable medical monitors

• Drones & compact imaging devices

Industrial Automation & Robotics

• I/O controller boards

• Robot sensors

• Industrial communication modules

Communication & Embedded Systems

• Routers

• Transceivers

• Data acquisition modules

• Embedded processor boards

IoT & Smart Devices

• Sensor modules

• Micro-control units

• Low-power communication devices

Medical Instruments

• Diagnostic tools

• Compact monitoring equipment

Adding these categories boosts semantic relevance for long-tail search terms like
"connector for wearable devices", "board-to-board connector for robotics", "14 pin female connector for IoT".

Q&A

Q: How many pins does the 2×7P side-in female connector have?

A: It contains 14 pins (2 rows × 7 pins), suitable for multi-signal or mixed power-and-Data Transmission.

Q: Can this connector support high-speed data signals?

A: Yes. The gold-plated contacts provide low signal loss and stable high-frequency performance, making it ideal for high-speed digital and RF applications.

Q: What is the durability of this connector?

A: It is designed to withstand hundreds of mating cycles while maintaining stable mechanical and electrical performance.

Q: Can it carry both power and data?

A: Yes. It supports dual-function transmission, depending on power/current requirements and PCB design.

Q: Is installation difficult?

A: No. The side-entry slide-in structure ensures easy alignment, fast installation, and reduced assembly errors.
