The SATA 7+15P SMT Female Socket Board-Level Connector (4.2mm) is a compact, high-precision surface-mount connector designed for direct integration into printed circuit boards (PCBs).
It enables stable power and high-speed Data Transmission between SATA devices such as HDDs, SSDs, and embedded storage modules.
Engineered with durable thermoplastic housing and gold/tin-plated contacts, this board-level connector ensures low Contact Resistance, excellent Signal Integrity, and reliable long-term performance.
Its SMT design allows easy placement on automated assembly lines, reducing manual labor and ensuring consistent quality across large production volumes.
Perfect for high-density PCB designs, this SATA female socket offers secure mating, vibration resistance, and long operational life — making it ideal for modern computing, industrial, and embedded systems.
Compact 4.2mm Design – Saves valuable PCB space while mAIntaining reliable data and power connection.
High-Speed Data Performance – Supports SATA III (6Gbps) transmission with minimal signal loss.
Gold/Tin-Plated Contacts – Provide low resistance and excellent corrosion protection for long-term stability.
Robust Housing – Prevents accidental disconnection and ensures durability under vibration and shock.
SMT Assembly Compatibility – Designed for pick-and-place automation and reflow soldering, ideal for mass production.
Environmental Resistance – Dustproof and moisture-resistant structure suitable for harsh operating conditions.
Versatile Configurations – Available in 7+15P SATA and other pin counts to support different PCB layouts.
The SATA SMT female socket is widely used in systems where compact, high-speed, and reliable connectivity is essential:
Consumer Electronics – Laptops, tablets, SSD enclosures, and portable storage devices.
Computing & Data Storage – SATA HDDs, SSDs, servers, NAS systems, and industrial computers.
Industrial Automation – Controllers, robotics, and machinery requiring rugged PCB connections.
IoT & Embedded Systems – Smart devices, edge computing modules, and embedded boards.
Telecommunication Equipment – Routers, base stations, and high-speed network devices.
Automotive & Medical Electronics – Systems needing stable, vibration-resistant signal transmission.
A: It supports multiple configurations, including SATA 7+15P and custom pin counts, adaptable to various PCB designs.
A: Yes. It is fully compatible with pick-and-place machines and reflow soldering processes, ideal for high-volume production.
A: Absolutely. With gold-plated contacts and precision design, it maintains signal integrity up to 6Gbps SATA III.
A: The connector endures over 500 mating/unmating cycles without significant signal degradation.
A: Yes. It offers resistance to vibration, oxidation, dust, and humidity, ensuring consistent operation even in industrial or outdoor conditions.
